Fiber splicer

BD-PON Fiber Splicing Machine


●Used for FTTH and ordinary fiber project
●Core to core alignment by PAS technology
● 8 sec splicing time and 30 sec heat time
●With 7200 mAh Ultra-large capacity Li battery
● 350 X or Y view, 280 X and Y view
●Large amplification and clear core
● 5 inch digital high-quality LCD screen, observe X and Y view at same time
● Three in one fixture, splicing single fiber, cable indoor and pig tail
● Built in large capacity lithium battery of 200 times splicing and heating
● Small size and light weight, 1.98KG including battery
●V type high power automatic heater with steel based thick film;high thermal efficiency, fast heating and long life



  •  1U 19 inch standard box EPON OLT with 4 PON ports
  •  Compliant with IEEE802.3ah YD/T1475-2006—EPON and China Telecom EPON Technical Requirements
  •  QoS based on port, VID, TOS and MAC address(32K Mac address)
  • Support priority queue scheduling, support SP, WRR or SP + WRR scheduling algorithm
  •  Support 4096 VLAN, transparent transmission and conversion, support VLAN stacking (QinQ)
  • Support 32K MAC’s line speed learning and aging, support MAC address restriction
  •  Support IEEE 802.1d (STP), 802.1w (RSTP) and MSTP Spanning Tree Protocol
  •  Support multicast Groups, IGMP v1/v2 snooping and IGMP Proxy
  •  Support port-based rate limitation and bandwidth control
  •  Support PON line AES and triple churing encryption
  • Support Dynamic Bandwidth Allocation (DBA)
  • Support ONU auto-MAC binding and filtering, support the ONU offline business configuration and automatically configure, manual/auto authentication
  • Support the use of the ACL rules for packet filtering
  • Support SNMP, telnet, CLI, OAM and Web management



BD-PON Ethernet Cable


1.Double Shields Assure the Anti-Jam and Data-Protection Strongly
2.Fast and Reliable Connection
3.Twisted Pairs with Bright Color for Easy Recognition
4.Ripcord and Footmark for Convenient Use
5.Smooth Jacket for Easy Pulling in Tight Space
6.Color in Light Grey, Dark Grey, Blue, White or as per Your Requirement
